ELEVATOR OVERLOAD SYSTEM , ELEVATOR WEIGHING DEVICE ,
ELEVATOR SPARE PARTS
Product Features:
1.Meets the requirements of EN81
2. Four-digit LED digital tube and multi-status indicator display
3.Multi-key operation, quick and easy debugging
4.Green high efficiency, low energy consumption power supply
5.One-piece design structure, no need for additional cables to connect
6.Easy to install, it only takes a few minutes to complete
Simple debugging, flexible operation, no need to predict the weight, intuitive display of the load
7.Support 2 groups of relay signal output (3 groups of relays are optional)
8 Suitable for multiple wire ropes from 4 to 16 mm in diameter
9. Size: 306mm*230mm*130mm
Product Description:
| Technical parameter | | | |
| Power supply voltage | AC/DC16-65V | Analog output(opeional) | |
| Power rating | ≤4W | Galvanically isolated | O |
| Alarm relays | 3 | Hold input | 12V-230V AC/DC |
| Max.switching valtage | 250VAC | Rope diameter | 4mm-16mm |
| Max.peak current | 5A | Measuring range | 1000kg-5000kg |
| Rated current | 3A | Maximum load | 10000kg |
| Rated load (resistive) in AC1 | 800VA | Dimensions | 306mm*230mm*130mm |
| Rated load (inductive)in AC15 | 200VA | Length of cable set | 3m(standard) |
Production Show:
Advantages:
Reliable & Trustworthy Product & Service Guarantee Technical Support
7 Year's experience in South Reliable products with Professional technical support
America &Europe Market with considerate service. available before & after sales!
good reputation.
Payment & Shipping:
Certifications:
